Servers


          ┌─────────────────┐  ┌───40G─────┐
          │Arista           │  │           │
 ◀──10G───│DCS-7050QX-32S-F │──┘           │
          │                 │      ┌───────────────┐       ┌────────────────┐
          └─────────────────┘      │Arista         │──1G───│Server 1        │
                   ║               │DCS-7050T-64-R │       └────────────────┘
                 160G              │               │             ...
                   ║               │               │       ┌────────────────┐
          ┌─────────────────┐      │               │──1G───│Server 18       │
          │Arista           │      └───────────────┘       └────────────────┘
 ◀──10G───│DCS-7050QX-32S-F │──┐           │
          │                 │  │           │
          └─────────────────┘  └───40G─────┘

The images are coming from a different host, they might trigger your adblocker. Generated with RRDtool.

Server 1

s1.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 2

s2.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 3

s3.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 4

s4.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 5

s5.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 6

s6.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 7

s7.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 8

s8.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 9

s9.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 10

s10.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 11

s11.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 12

s12.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 13

s13.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2630 0 @ 2.30GHz
384G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 14

s14.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2640 0 @ 2.50GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 15

s15.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2640 0 @ 2.50GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 16

s16.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2640 0 @ 2.50GHz
128G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 17

s17.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2650 0 @ 2.60GHz
384G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Server 18

s18.obsda.ms

40 VMs (max)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2650 0 @ 2.60GHz
384G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
2 x 900GB 10K SAS

Mega 1

m1.obsda.ms

40 VMs (max, as storage permits)
Dell PowerEdge R620 w/ 2 x Intel(R) Xeon(R) CPU E5-2650 v2 @ 2.60GHz
384G RAM
Dell PERC H710 Mini
2 x 146GB 15K SAS
6 x 1.2TB 10K SAS
